| Model | E8 |
| Main Unit Dimensions (excluding water tank) | 650 mm (L) × 550 mm (W) × 910 mm (H) (excluding water tank) |
| Main Unit Net Weight | 45.1 kg |
| Input Voltage | 110 V AC |
| Permissible Voltage Fluctuation | ±10% Voltage Tolerance |
| Rated Current | 0.1 A – 4 A |
| Frequency | 50 Hz ± 1 Hz |
| Power Fuse | 2 × 250 V, T6.3 AH Fuse |
| Maximum Power Consumption | 400 VA Maximum Apparent Power |
| Water Tank Dimensions | 400 mm (L) × 140 mm (W) × 220 mm (H) |
| Water Tank Capacity | 5 L Water Tank Capacity |
| Coolant Flow Rate at 100% | ≥ 50 mL/min Coolant Flow Rate at 100% |
| Water Quality and Hardness Range for Water Tank | Distilled Water / Purified Water with Hardness < 6.5 mmol/L |
| Recommended Coolant for Water Tank | Recommended Coolant: Distilled Water / Purified Water |
| Maximum Allowable Load for Suspension | ≤ 1.5 kg Maximum Allowable Suspension Load |
| Operating Environment | Temperature: 5°C ~ 40°C; Humidity: 15% RH ~ 80% RH; Atmospheric Pressure: 860 hPa ~ 1060 hPa |
| Transportation and Storage Environment | Temperature: -40°C ~ 55°C; Humidity: 8% RH ~ 93% RH; Atmospheric Pressure: 700 hPa ~1060 hPa |
| Date of Manufacture | Refer to Unit Body, Individual Packaging Box, Warranty Card |
| Service Life | 10 Years Service Life for the Main Unit from Date of Manufacture |
| Special Note | *This main unit is classified as conventional equipment (i.e., a sealed unit without ingress protection). |
